Ozone Generators & Electric Controls

APG Series Ozone Generators

RK-APG-1,RK-APG-2,RK-APG-3

RK-APG-1,RK-APG-2,RK-APG-3

Standard Features

Featuring Advanced Plasma Gap technology, all APG systems are compatible with any operating voltage and do not require desiccant air dryers to properly function. Our APG Series ozone generators offer improved water quality and clarity while reducing the amount of chlorine and chemicals used within your display. Units oxidize up to 99.99% of harmful microorganisms, while eliminating oils, lotions and other contaminants from your water. Each APG System is designed to offer customers a high output / low energy cost solution with a simple and inexpensive cost of ownership. Use of our systems will further aid in the reduction of wear and tear on additional life support equipment used within your life support system.

All APG Series units offer the following:

Model Recommended Air Flow Rates Max Power Consumption
@ 120VAC 60 Hz. /
@ 220 VAC 50 Hz.
Dimensions LHW (inches) Weight Recommended Skimmer Models Manuals
RK-APG-1 12 SCFH/5 LPM .1 Amps @ 120 VAC 60 Hz.
.05 Amps @ 240 VAC 50 Hz.
8" x 14.3" x 3.2" 10 LBS./4.5 KGS X-Flo 6-2.5/X-Flo 6-3.5
RK-APG-2 12 SCFH/5 LPM .2 Amps @ 120 VAC 60 Hz.
.1 Amps @ 240 VAC 50 Hz.
8" x 14.3" x 3.2" 10 LBS./4.5 KGS RK10AC
RK-APG-3 15 SCFH/7 LPM .31 Amps @ 120 VAC 60 Hz.
.15 Amps @ 240 VAC 50 Hz.
8" x 21.5" x 3.2" 15 LBS/6.8 KGS RK25PE/RK50PE
* All models are avialable with ORP Controller and Probe

Corona Discharge Series Ozone Generators

Standard Features

RK-7GV

RK-7GV

RK2 Systems models RK-2G through RK-45G produce ozone at 2, 5, 7, 15, 25, 45grams/hour at 3-5% by weight. All systems operate under vacuum, for safety, efficiency and ease of operation. Each model has configurable feed-gas options (integrated oxygen concentrator system is standard), multiple safety features, self-diagnostic switching and robust construction. Variable ozone output control is available on models RK5G through RK-45G.

Ozone is the most powerful oxidizer and disinfectant that can safely be used in multiple industrial and commercial applications. It destroys all organic molecules, renders dissolved metals insoluble and oxidizes inorganic contaminants. With a relative sanitizing strength of 1 PPM aqueous ozone to 200 PPM chlorine, ozone is safe for all surfaces (excluding natural latex rubber).

Ozone is an EPA approved antimicrobial and listed as safe for discharge into surface and groundwater; FDA approved as an antimicrobial food additive, and USDA approved as an antimicrobial organic food additive. Leaving no measurable residual (no rinse), RK2 Systems Corona Discharge series provide a non-corrosive solution for continuous or on-demand sanitation. Each of our units are built to UL standards, are NSF validated for antimicrobial efficacy and safety and are designed as totally integrated systems providing a synergistic approach to water or surface sanitation in multiple commercial and industrial applications while giving facility operators a simple, automated, low maintenance system.

All Corona Discharge Series units offer the following:

Specifications

Model Recommended Air Flow Rates Max Power Consumption
@ 120VAC 60 Hz. /
@ 240 VAC 50 Hz.
Dimensions LHW (inches) Weight Concentration By Weight Recommended Skimmer Models air cooled/water cooled water pipe size and connection water flow rate for cooling line
RK-2G 3 SCFH/1.4 LPM 5.5 Amps @ 120 VAC 60Hz. 16" X 26.5" X 11.5" 50 LBS./23 KGS 2.5% - 3.0% by weight RK10AC/RK25PE/RK50PE air cooled N/A N/A
RK-2G-50 3 SCFH/1.4 LPM 2.5 Amps @ 240 VAC 50Hz. 16" X 26.5" X 11.5" 50 LBS./23 KGS 2.5% - 3.0% by weight RK10AC/RK25PE/RK50PE air cooled N/A N/A
RK-5G 6 SCFH/2.8 LPM 5.5 Amps @ 120 VAC 60 Hz. 16" X 26.5" X 11.5" 52 LBS./24 KGS 2.0% - 2.5% by weight RK75PE/RK75PE-HF/RK150PE/RK150PE-HF air cooled N/A N/A
RK-5G-50 6 SCFH/2.8 LPM 2.5 Amps @ 220 VAC 50 Hz. 16" X 26.5" X 11.5" 52 LBS./24 KGS 2.0% - 2.5% by weight RK75PE/RK75PE-HF/RK150PE/RK150PE-HF air cooled N/A N/A
RK-7GV 7 SCFH/3.3 LPM 5.5 Amps @ 120 VAC 60 Hz. 16" X 26.5" X 11.5" 52 LBS./24 KGS 2.5% - 3.0% by weight RK300PE/RK300PE-HF air cooled N/A N/A
RK-7GV-50 7 SCFH/3.3 LPM 2.5 Amps @ 220 VAC 50 Hz. 16" X 26.5" X 11.5" 52 LBS./24 KGS 2.5% - 3.0% by weight RK150PE/RK150PE-HF/RK300PE/RK300PE-HF air cooled N/A N/A
RK-15GV 13 SCFH/6 LPM 10 Amps @ 120 VAC 60 Hz. 24.4" X 39.2" X 11.7" 150 LBS./70 KGS 2.5% - 3.0% by weight RK600PE water cooled 1/4" FPT BRASS CONNECTION .1 GPM/.4 LPM
RK-15GV-50 13 SCFH/6 LPM 5 Amps @ 220 VAC 50 Hz. 24.4" X 39.2" X 11.7" 150 LBS./70 KGS 2.5% - 3.0% by weight RK600PE water cooled 1/4" FPT BRASS CONNECTION .1 GPM/.4 LPM
RK-25GV 17 SCFH/8 LPM 10 Amps @ 120 VAC 60 Hz. 24.4" X 39.2" X 11.7" 150 LBS./70 KGS 3% - 4% by weight RK1000PE/RK2000PE water cooled 1/4" FPT BRASS CONNECTION .1 GPM/.4 LPM
RK-25GV-50 17 SCFH/8 LPM 5 Amps @ 220 VAC 50 Hz. 24.4" X 39.2" X 11.7" 150 LBS./70 KGS 3% - 4% by weight RK1000PE/RK2000PE water cooled 1/4" FPT BRASS CONNECTION .1 GPM/.4 LPM
RK-45GV 30 SCFH/14.1 LPM 17 Amps @ 120 VAC 60 Hz. 24.4" X 39.2" X 13.2" 175 LBS./79 KGS 4% by weight water cooled 1/4" FPT BRASS CONNECTION .2 GPM/.7 LPM
RK-45GV-50 30 SCFH/14.1 LPM 8 Amps @ 220 VAC 50 Hz. 24.4" X 39.2" X 13.2" 175 LBS./79 KGS 4% by weight water cooled 1/4" FPT BRASS CONNECTION .2 GPM/.7 LPM
* All models are avialable with ORP Controller and Probe

System Controller/Monitor

Until now, performing even the simplest functions with a controller required technical or electronic expertise. The RK2 Systems - System Controller/ Monitor makes maintaining the optimum aquatic environment easy.

Our RK2 Systems - system controller/ monitor is constructed with only the highest quality components. The heart of our system controller / monitor is an INTEL microprocessor which manages all of the activities of the controller gathered by the controller is processed digitally. Our RK2 Systems controller/ monitor Architecture includes Digital Signal Processing (DSP) hardware and software that provides accurate and repeatable readings over the life of the System Controller.

In addition, the microprocessor design provides unsurpassed flexibility, as reflected by the variety of the software options that are available for our control/monitoring system.

RK2 System Controller/ Monitor includes the following features:

RK2 ORP Temperature PH Controller

RK2 ORP Temperature
PH Controller w/probes
